300-630 – Implementing Cisco Application Centric Infrastructure - Advanced

Loading demo links...

Showing 4–6 of 10 questions

Question 4 (Advanced ACI Policies and Integrations)

Refer to the exhibit. An engineer must have communication between EPG1 in VRF1 and External

EPG in VRF2. Which three actions should be taken for the defined subnets in the L3Out External

EPG to accomplish this goal? (Choose three.)

Select all that apply, then click Submit answer.

  • ○

    Enable Shared Route Control Subnet
  • ○

    Enable External Subnets for External EPG
  • ○

    Enable Export Route Control Subnet
  • ○

    Enable Shared Security Import Subnet
  • ○

    Enable Aggregate Shared Routes
  • ○

    Enable Import Route Control Subnet
Question 5 (Multipod)

A network engineer configured an active-active firewall cluster that is stretched across separate pods in the Cisco ACI fabric. Which two implementation setups for anycast services are available?

(Choose two.)

Select all that apply, then click Submit answer.

  • ○

    Modify the Cisco ACI contract scope
  • ○

    Modify the MAC address on the second firewall
  • ○

    Configure the firewalls behind an EPG subnet
  • ○

    Deselect No Default SVI Gateway under EPG Subnet
  • ○

    Deploy a Layer 4 to Layer 7 service graph with PBR
Question 6 (Advanced ACI Policies and Integrations)

An engineer created a Cisco ACI environment in which multiple tenants reuse the same contract. The requirement is to prevent inter-tenant communication. Which action meets this requirement?

Select an option, then click Submit answer.

  • ○

    Create the contract in the user tenant with the scope set to VRF and exported to other tenants
  • ○

    Create the contract in the common tenant with the scope set to Tenant
  • ○

    Create the contract in the user tenant with the scope set to Global and exported to other tenants
  • ○

    Create the contract in the common tenant with the scope set to Global
